10056845-120LF

Product Detailed Parameters

• Description：CONN HEADER R/A 20POS 2.54MM
• Series：Quickie™
• Mfr：Amphenol ICC (FCI)
• Package：Tube,Box
• Connector Type：Header
• Contact Type：Male Pin
• Pitch - Mating：0.100" (2.54mm)
• Number of Positions：20
• Number of Rows：2
• Row Spacing - Mating：0.100" (2.54mm)
• Number of Positions Loaded：All
• Style：Board to Cable/Wire
• Shrouding：Shrouded - 4 Wall
• Mounting Type：Through Hole, Right Angle
• Termination：Solder
• Fastening Type：Detent Lock
• Contact Length - Mating：0.236" (6.00mm)
• Contact Length - Post：0.079" (2.00mm)
• Overall Contact Length：-
• Insulation Height：0.362" (9.20mm)
• Contact Shape：Square
• Contact Finish - Mating：Gold, GXT™
• Contact Finish Thickness - Mating：30.0µin (0.76µm)
• Contact Finish - Post：Tin
• Contact Material：Copper Alloy
• Insulation Material：Thermoplastic
• Features：Keying Slot
• Operating Temperature：-
• Ingress Protection：-
• Material Flammability Rating：UL94 V-0
• Insulation Color：Black
• Current Rating (Amps)：-
• Voltage Rating：-
