2N7002KW

Product Detailed Parameters

• Description：60V 340MA 5@10V,500MA 200MW 2.5V
• Series：-
• Mfr：Shenzhen Slkormicro Semicon Co., Ltd.
• Package：Tape & Reel (TR),Cut Tape (CT)
• FET Type：N-Channel
• Technology：MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss)：60 V
• Current - Continuous Drain (Id) @ 25°C：340mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On)：4.5V, 10V
• Rds On (Max) @ Id, Vgs：5Ohm @ 500mA, 10V
• Vgs(th) (Max) @ Id：2.5V @ 1mA
• Gate Charge (Qg) (Max) @ Vgs：-
• Vgs (Max)：±20V
• Input Capacitance (Ciss) (Max) @ Vds：40 pF @ 10 V
• FET Feature：-
• Power Dissipation (Max)：200mW (Ta)
• Operating Temperature：150°C (TJ)
• Grade：-
• Qualification：-
• Mounting Type：Surface Mount
• Supplier Device Package：SOT-323
• Package / Case：SC-70, SOT-323
