B511-2

Product Detailed Parameters

• Description：MOD DIODE SCR 25A 120VAC ISO QC
• Series：B-2
• Mfr：Sensata-Crydom
• Package：Bulk,Box
• Structure：Bridge, Single Phase - SCRs/Diodes (Layout 1)
• Number of SCRs, Diodes：2 SCRs, 2 Diodes
• Voltage - Off State：400 V
• Current - On State (It (AV)) (Max)：-
• Current - On State (It (RMS)) (Max)：-
• Current - Non Rep. Surge 50, 60Hz (Itsm)：250A @ 60Hz
• Operating Temperature：-40°C ~ 125°C (TJ)
• Mounting Type：Chassis Mount
• Package / Case：Module with Isolation Barriers
• Voltage - Gate Trigger (Vgt) (Max)：2.5 V
• Current - Gate Trigger (Igt) (Max)：60 mA
• Current - Hold (Ih) (Max)：-
• Grade：-
• Qualification：-

Download product information
