C2D05120E

C2D05120E

  • Description:DIODE SIL CARB 1.2KV 17.5A TO252
  • Series:Zero Recovery™
  • Mfr:Wolfspeed, Inc.
  • Package:Tube

SKU:84f33c9dfd61 Category: Brand:

Consult the customer manager about the wholesale price.

consultation hotline:86-132-6715-2157

email:839314116@qq.com
Contact the product manager for consultation. One-stop consultation is available.


Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

*
*
*
Submitting!
Submission successful!
Submission failed!
Email error!
Phone number error!

Product Detailed Parameters

  • Description:DIODE SIL CARB 1.2KV 17.5A TO252
  • Series:Zero Recovery™
  • Mfr:Wolfspeed, Inc.
  • Package:Tube
  • Technology:SiC (Silicon Carbide) Schottky
  • Voltage - DC Reverse (Vr) (Max):1200 V
  • Current - Average Rectified (Io):17.5A
  • Voltage - Forward (Vf) (Max) @ If:1.8 V @ 5 A
  • Speed:No Recovery Time > 500mA (Io)
  • Reverse Recovery Time (trr):0 ns
  • Current - Reverse Leakage @ Vr:200 µA @ 1200 V
  • Capacitance @ Vr, F:455pF @ 0V, 1MHz
  • Mounting Type:Surface Mount
  • Package / Case:TO-252-3, DPAK (2 Leads + Tab), SC-63
  • Supplier Device Package:TO-252-2
  • Operating Temperature - Junction:-55°C ~ 175°C
  • Grade:-
  • Qualification:-
