TP0610K-T1-E3

Product Detailed Parameters

• Description：MOSFET P-CH 60V 185MA SOT23-3
• Series：TrenchFET®
• Mfr：Vishay Siliconix
• Package：Tape & Reel (TR),Cut Tape (CT)
• FET Type：P-Channel
• Technology：MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss)：60 V
• Current - Continuous Drain (Id) @ 25°C：185mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On)：4.5V, 10V
• Rds On (Max) @ Id, Vgs：6Ohm @ 500mA, 10V
• Vgs(th) (Max) @ Id：3V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs：1.7 nC @ 15 V
• Vgs (Max)：±20V
• Input Capacitance (Ciss) (Max) @ Vds：23 pF @ 25 V
• FET Feature：-
• Power Dissipation (Max)：350mW (Ta)
• Operating Temperature：-55°C ~ 150°C (TJ)
• Grade：-
• Qualification：-
• Mounting Type：Surface Mount
• Supplier Device Package：SOT-23-3 (TO-236)
• Package / Case：TO-236-3, SC-59, SOT-23-3
