VCO97S8-110-170K

Product Detailed Parameters

• Description：9*7*2.2 110-170MHz 3.3-6V -85dBc
• Series：VCO97S8
• Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
• Package：Tape & Reel (TR),Strip
• Frequency Range：110 ~ 170MHz
• Frequency - Center：-
• Voltage - Supply：3.3V ~ 6V
• Tuning Voltage (VDC)：-
• 2nd Harmonic, Typ (dBc)：-10
• Icc Max：-
• Pushing (MHz/V)：-
• Power (dBm)：-
• Phase Noise Typ (dBc/Hz)：-85
• Operating Temperature：-30°C ~ 85°C
• Package / Case：-
• Size / Dimension：0.299" L x 0.228" W (7.60mm x 5.80mm)
• Height：0.087" (2.20mm)
